Embossed Aluminum Coil Plate:

Embossed aluminum coil is essentially aluminum tread plate, also known as aluminum checker plate, aluminum embossed sheet, etc. It’s an aluminum tread plate in a roll shape, so that embossed aluminum tread coil satisfies the cutting requirements of the length and other specifications, and greatly facilitates transportation and storage. Similarly, the Embossed aluminum coil also is divided into 1 series, 3 series, 5 series, and 6 series. The surface patterns include diamond/one bar, large/small 5 bars, 2 bars, 3 bars, etc. Therefore, embossed aluminum coil plates of different alloy grades, are matched with different surface patterns, to give full play to the maximum effect.
Embossed Aluminum Coil

Embossed Aluminum Coil Typical Alloy Grades:

The specific alloy grades of embossed aluminum coil divided into 1-6 series, include 1100, 1060, 1070, 3003, 3105, 5052, 5754, 5005, 5083, 6061,etc.

1100 Embossed Aluminum Coil

Attribute: 1 series pure aluminum tread plate coil (Al content: ≥99%)
Properties: Excellent ductility, processing formability, weather resistance, silver-white luster, highly decorative, low price, etc
Common Temper: h14, h114, etc.
Typical Uses: Large area laying of wall or floors of cold storage/garage/other constructions.

Elements Si Fe Cu Mn Zn Others Al
Content 0.95 0.05-0.2 0.03 0.1 0.05 Remain

5754 Embossed Aluminum Coil

Attribute: 5 series Al-Mg aluminum embossed coil
Properties: Excellent corrosion and weather resistance, sufficient strength, high fatigue strength, good weldability, cost-effective, etc
Common Temper: aluminium 5754 h114
Typical Uses: Wind tower internal, Various vehicles internal, Ship silo bottoms, Aerial working rotary ladder, etc.

Elements Si Fe Cu Mn Mg Cr Zn Ti Others Al
Content 0.4 0.4 0.1 0.5 2.6–3.6 0.3 0.2 0.2 0.05 Remain

Embossed Aluminum Coil

Embossed Aluminum Coil Grades with Various Surface Patterns:

There are a variety of surface patterns to match various embossed aluminum coil grades, such as diamond/ single bar, big/ small 5 bars, 3 bars, 2 bars,etc,

Diamond Embossed Aluminum Coil

Describe: The surface shows a pattern like one diamond after another.
Features: Concise, sparkling, beautiful, in line with modern architectural decoration style.
Application: Wainscot of garages/ gyms/ offices/ others, truck beds and other vehicle exteriors, furniture edging, etc.
Typical Alloy Products: 1100 h14 aluminum diamond coil, 6061-t6 aluminum diamond tread plate, etc.

Embossed Aluminum Coil with 5 Bars Surface Patterns

Describe: The surface presents a pattern of 5 lines in group after group, including small/ big 5 bars line.
Features: More slip resistance, wear resistance, economical.
Application: Floors, stairs, toolboxes, etc.
Typical Alloy Products: small 5 bars 3003 aluminum tread plate coil, extra-wide 5754 embossed aluminum coil with 5 bars surface patterns, etc.
Embossed Aluminum Coil

Mingtai Embossed Aluminum Coil on Sale:

Mingtai Aluminum supplies embossed aluminum coils with the complete alloy grades, and various specifications for your choice, that also can be customized !

Alloy Series Typical Alloy Surface Pattern Typical Temper Thickness(mm) Width(mm) Length(mm)
1 series 1100, 1060, 1050 diamond,               one/ single bar, small/ big 5 bar, 2 bar, 3 bar,                      pointer shaped, etc H14, H16, H18, H1*,  H24, H2*, H111, H114, H11*, etc ≥0.8 100-2650 C
3 series 3003(4017),  3004, 3104, 3105 H14, H16, H18, H1*, H22, H24, H2*, H11*, H32*, etc ≥0.8 100-2650 C
5 series 5052, 5754, 5086, 5083 H114, H116, H112, H111, H14, H1*,H22, H2*, H3*,H321, etc ≥0.8 100-2650 C
6 series 6061, 6082, 6063 T6,T651,H112, etc ≥0.8 100-2650 C
